Instructions for ordering
| 型号 | 主要尺寸(mm） | ||||||
| Φ | D | d | L | L1 | W | S | |
| DTL-16Q | 8.4 | 10 | 5.5 | 70 | 32 | 16 | 3.0 |
| DTL-25Q | 8.4 | 12 | 7 | 75 | 34 | 18 | 3.5 |
| DTL-35Q | 10.5 | 14 | 8.5 | 85 | 40 | 20 | 3.5 |
| DTL-50Q | 10.5 | 16 | 9.5 | 90 | 42 | 23 | 4.0 |
| DTL-70Q | 12.5 | 18 | 12 | 102 | 47 | 26 | 4.5 |
| DTL-95Q | 12.5 | 21 | 13 | 112 | 50 | 28 | 5.0 |
| DTL-120Q | 14.5 | 23 | 15 | 120 | 53 | 30 | 5.5 |
| DTL-150Q | 14.5 | 25 | 16 | 126 | 55 | 34 | 6.0 |
| DTL-185Q | 16.5 | 27 | 18 | 133 | 58 | 37 | 6.5 |
| DTL-240Q | 16.5 | 30 | 20 | 140 | 60 | 40 | 7.5 |
| DTL-300Q | 21 | 34 | 23 | 165 | 65 | 45 | 8.5 |
| DTL-400Q | 21 | 38 | 26 | 170 | 70 | 52 | 9.5 |
| DTL-500Q | 21 | 42 | 29 | 190 | 75 | 60 | 10.0 |
| DTL-630Q | 方头 | 54 | 34 | 220 | 80 | 78 | 10.5 |
| DTL-800Q | 方头 | 60 | 38 | 270 | 90 | 100 | 11.0 |
